45 Questions·
multiple choice

Sample Questions

1multiple choice
1 marks

The density of a substance is 13.6 g cm⁻³. Which of the following correctly states its density in SI units and its relative density?

Show answer

13600 kg m⁻³ and relative density = 13.6

Step 1: Conversion: 1 g cm⁻³ = 1000 kg m⁻³, so 13.6 g cm⁻³ = 13600 kg m⁻³. Step 2: Relative density = Density of substance / Density of water = 13600 / 1000 = 13.6. Step 3: Relative density is dimensionless and equals the numerical value of density in g cm⁻³. Option 2 wrongly divides instead of multiplying by 1000. Option 3 confuses the SI value with relative density. Option 4 multiplies by 10 instead of 1000.

2multiple choice
1 marks

A rectangular glass block is 40 cm long, 20 cm wide and 5 cm thick. Its mass is 8 kg. What is the density of glass in g cm⁻³?

Show answer

2 g cm⁻³

Step 1: Volume = length × breadth × height = 40 × 20 × 5 = 4000 cm³. Step 2: Mass = 8 kg = 8000 g (convert to grams). Step 3: Density = M/V = 8000 / 4000 = 2 g cm⁻³. Option 0.5 arises from not converting kg to g. Option 20 comes from using 400 cm³ as volume (missing one dimension). Option 4 results from using 2000 g instead of 8000 g.

3multiple choice
1 marks

A wooden block of mass 300 g and density 0.75 g cm⁻³ is placed in glycerine of density 1.26 g cm⁻³. Which statement correctly describes what happens?

Show answer

It floats with approximately 59.5% of its volume inside glycerine

Step 1: Density of wood (0.75 g cm⁻³) < Density of glycerine (1.26 g cm⁻³), so the block floats. Step 2: Fraction submerged = ρ_wood / ρ_glycerine = 0.75 / 1.26 = 0.595 ≈ 59.5%. Step 3: So approximately 59.5% of the block is inside glycerine and 40.5% is outside. Option 2 is wrong because the wood's density is less than glycerine's. Option 3 confuses density of wood (0.75) as a direct percentage. Option 4 has no physical basis here.

4multiple choice
1 marks

An iceberg has density 0.9 g cm⁻³ and floats in sea water of density 1.02 g cm⁻³. If the total volume of the iceberg is 1000 m³, what volume (in m³) is visible ABOVE the sea surface?

Show answer

117.6 m³

Step 1: Fraction submerged = ρ_ice / ρ_sea water = 0.9 / 1.02 = 0.8824. Step 2: Volume submerged = 0.8824 × 1000 = 882.4 m³. Step 3: Volume above surface = 1000 – 882.4 = 117.6 m³. Option 882.4 m³ is the submerged part, not the visible part. Option 100 m³ uses ratio 0.9:1 (using fresh water density). Option 900 m³ uses incorrect fraction.

+41 more questions available

Practice All

Frequently Asked Questions

What are the important topics in Physical Quantities and Measurement for ICSE Class 8 Physics?
Key topics in Physical Quantities and Measurement include Physical Quantities and Measurement - Concept Map, Chapter Overview: Physical Quantities and Measurement, Density Concept Map - Main Topics and Subtopics. These are the concepts ICSE Class 8 examiners draw on most — study them first, then practise related questions.
How to score full marks in Physical Quantities and Measurement — ICSE Class 8 Physics?
Understand the core concepts first, then work through the 45 practice questions available for this chapter. Revise formulas and definitions regularly, and use flashcards for quick recall before the exam.
How many important questions are there in Physical Quantities and Measurement?
There are 45 practice questions available for Physical Quantities and Measurement. These cover multiple question types including MCQs, short answer, and long answer questions.
